VESAFE Graffiti Интеллектуальное маломощное сообщение посетителя внутреннего двора Кошачий глаз Беспроводной мониторинг Wi Fi Визуальный дверной звонок Мобильный просмотр

product Product name Mini waterproof WiFi wireless visual intercom doorbell
Optional
describe characteristic Wireless connection, ultralow power consumption, remote active wakeup, fast start
purpose
Wake up method Door bell button wakes up, PIR human body detection wakes up, mobile phone actively wakes up
Alarm push Quickly push within 1 second
system Low power scheme HiSilicon Liteos Low Power Solution
Number of online users Multiple users watching online simultaneously
Dynamic domain name Comes with a dynamic domain name
Adopting the powerful and highperformance programmable media Hi3518E from HiSilicon, with builtin ARM926 @ Max. 440MHz and highspeed protocol
collection image sensor 1/2.7 inch 1080p progressive scan CMOS sensor
Sensor performance
Signaltonoise ratio 39dB
Lens/visual angle 2.6mm @ F2.0/166 °
night vision Dual filter automatic switching, 6 850nm highpower infrared lights, night vision 10 meters
IR control Turn on the night vision function of IR and enable automatic detection of infrared and ICR; IR disabled night vision function disabled, infrared constantly off, ICR fixed in day vision mode
Compression standard
Encoding processing 1080P/15fps+720P/15fps+VGA/30fps+QVGA/30fps+1080P@1fsJPEG
resolving power 1080p
Code rate CBR/VBR two rate control modes, with an output rate range of 1284096kbps
15fps (1080p)
audio frequency input 1 builtin 48dB microphone
output Built in speaker (8 Ω 1W)`
Intercom Bidirectional voice intercom with builtin echo cancellation
Compression standard/bit rate ADPCM/32kbps
network Network Protocol TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P, etc.
wireless network 802.11b/g/n
Wireless network security WPS secure encryption
Wireless connection One click WIFI configuration
videotape Recording method Mobile detection recording, doorbell button triggered recording, manual recording
storage
other
power dissipation Standby current 120 μ A working current 170MA
work environment Working temperature: -10~50 , working humidity<>
Installation method Installation of wall mounted doors
material quality ABS plastic
Product size 14 * 4.6 * 2.8CM
Single machineExcluding Dingdong) Packaging size 8.5 * 18 * 4.5CM
Packaging weight 0.25KG (excluding battery) 0.3KG (including battery) 0.37KG (including battery and charging cable)
Full container size 44.5 * 38 * 24.5CM
Full container weight 12.8KG (excluding battery) 17.3KG (including battery) 18.3KG (including battery and charging cable)
Full container quantity 50 units
Set(including Dingdong) Packaging size 21 * 8.7 * 8CM
Packaging weight 0.27KG (excluding battery) 0.36KG (including battery) 0.38KG (including battery and charging cable)
Full container size 43.3*28*42CM
Full container weight 8.9KG (excluding battery) 11.6KG (including battery) 12.6KG (including battery and charging cable)
Full container quantity 30 units
