ESCAM K104 Onvif 4-канальный мини-сетевой видеорегистратор NVR + QD300 HD 720P 1/4 дюйма 1,0 мегапикселя Onvif водонепроницаемый комплект IP-камеры P2P (черный)

Key Features:

1) 1/4 inch 1.0 Megapixel progressive scan CMOS

2) H.264 dual-stream encoding

3) Max 25/30fps@720P(1280x720)

4) DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC

5) Multiple network monitoring: Web viewer, CMS

6) 3.6mm fixed lens

7) Max. IR LEDs Length 15m

8) DC 12V 1A

9) Model: QD300

Specification:

Camera:

1) Image Sensor: 1/4 inch 1.0 Megapixel progressive scan CMOS

2) Effective Pixels: 1280(H)x720(V)

3) Scanning System: Progressive

4) Electronic Shutter Speed: Auto/Manual 1/3(4)~1/10000

5) Min. Illumination: Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2, 0Lux (IR on)

6) S/N Ratio: More than 50dB

7) Video Output: N/A

Camera Features:

1) Max. IR LEDs Length: 15m

2) Day/Night: Auto(ICR) / Color / B/W

3) Backlight Compensation: BLC/ HLC/ DWDR

4) White Balance: Auto/Manual

5) Gain Control: Auto/Manual

6) Noise Reduction: 3D

7) Privacy Masking: Up to 4 areas

Lens:

1) Focal Length: 3.6mm

2) Max Aperture: F1.8

3) Focus Control: Manual

4) Angle of View: H: 70 degree

5) Lens Type: Fixed lens

6) Mount Type: Board-in Type

Video:

1) Compression: H.264

2) Resolution: 720P(1280x720) / D1(704x576 / 704x480) /CIF(352x288 / 352x240)

Frame Rate:

1) Main Stream: 720P (1 - 25/30fps)

2) Sub Stream: D1/CI F(1 - 25/30fps)

3) Bit Rate: H.264 16K - 8192Kbps

Audio:

1) Compression: N/A

2) Interface: N/A

Network:

1) Ethernet: RJ-45 (10/100Base-T)

2) Wi-Fi: N/A

3) Protocol: IPv4, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP

4) ONVIF: ONVIF Profile S

5) Max. User Access: 10 users

6) Smart Phone: iPhone, iPad, Android

7) P2P: iPhone, Android Mobile App

Auxiliary Interface:

1) Memory Slot: N/A

2) RS485: N/A

4) Alarm: N/A

5) PIR Sensor Range: N/A

General:

1) Power Supply: DC12V 1A

2) POE: N/A

3) Power Consumption: <4W

4) Working Environment: -30 - +60 degree, Less than 95 percent RH

5) Ingress Protection: N/A

6) Vandal Resistance: N/A

ESCAM MINI NVR:

Key Features：

1) Can connect IP camera, IP speed dome camera and DVS; support Onvif protocol;

2) Compatible with main brand IP cameras: AXIS, SONY, Panasonic, SANYO, BOSCH, SAMSUNG, Honeywell, VIVOTEK, Ambarella, HIKVISION, DAHUA, Histream, Grandstream, TOPSEE, Launch, WISION, HYVISION, WAPA etc

3) Support megapixel HD network video preview, storage and playback

4) Click any area and zoom in or zoom out on the image by mouse

5) Support digital zooming under preview and playback modes

6) Support search, playback and backup by event

7) Support 4ch playback simultaneously

Specification:

1) Model Number: K104

2) Operating System: Embedded LINUX operating system

3) Image Code Control: Image code quality adjustable, variable bit stream and

constant bit stream optional

4) Dual Stream: Each channel can set main stream and sub stream

5) Video Standard: 1080P (1920x1080) 30fps/ 960P/(1280x960)/720P

(1280x720)30fps

6) Monitoring Image Quality: 1080P(1920x1080) / 960P/(1280x960)/720P (1280x720)

7) Image Motion Detection: Each screen can set mutiple detection areas and set 6-level sensitivity（IPC Support）

8) Recording Playback Quality: 4ch playback in 4ch 720/960P mode;1ch 1080P playback in 1/4ch 1080P mode

9) Region Cover: Every channel can set 4 cover regions（IPC Support）

10) Recording Mode: Support manual, auto, dynamic detection, alarm trigger

record mode(Partly needs IPC Support)

11) Backup Way: Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup

12) Operation Way: Mouse

13) Local Login: User name and password

14) Recording Storage: Local HDD, network

15) External Ports:

- Video Input:

-- 4x(1280*720)+sub(960*576)+4Ref.+4Play, support 4ch 1MP IP camera

-- 4x(1280*960)+sub(960*576)+1Ref.+4Play, support 4ch 1.3MP IP camera

-- 4x(1920*1080)+sub(960*576)+4Ref.+1Play, support 4ch 2MP IP camera

-- 1x(1920*1080)+sub(960*576)+4Ref.+1Play, support 1ch 2MP IP camera

-- 4x(720*576)+sub(352*288)+4Ref.+4Play, support 4ch 0.4MP IP camera

- Audio Input: 4ch network audio input

- Video Output: 1ch VGA+1ch HDMI

- Network Port: 1 RJ45,10M/100M self-adaptive LAN port

- USB Port: 2 USB 2.0 ports

- Wireless Port: 3G, WIFI

16) HDD: Mobile HDD/E-SATA/USB Disk

17) Mobile Surveillance: Support( iPhone, Windows Mobile, BlackBerry, Symbian,

Android) smart phone

18) Power Supply: 5V2A

19) Power Consumption: <=10W（without HDD）

20) Working Temperature: -10～+55 degrees

21) Working Humidity: 10-90 percent
